The EL-USB-ULT-LCD is designed to monitor vaccines in cryogenic dry ice storage.
This standalone data logger measures and stores more than 32,000 temperature readings from its high accuracy thermocouple
temperature probe.
The user can easily set up the logger and view downloaded data by plugging the data logger into a PC’s USB port and using the free
EasyLog software. Data can then be graphed, printed and exported to other applications for detailed analysis.
The high contrast LCD can show a variety of temperature information. At the touch of a button, the user can cycle between the
current, maximum and minimum stored values for temperature.
The data logger is supplied with a lithium metal battery which typically gives 2 years’ logging life.
There are no reviews yet.
Questions and answers of the customers
There are no questions yet, be the first to ask something for this product.
SPECIFICATIONS
Temperature measurement range: -100 to +100°C (-148 to +212°F)
Internal resolution: 0.5°C (1°F)
Accuracy (overall error): ±2.5°C (±4.5°F) typical
Logging rate: User selectable between 1 second & 12 hours
Operating temperature range: -10 to +40°C (+14 to +104°F) (data logger only)
Battery Life: 2 years (at 25°C and 1 minute logging rate)
Readings: 32,510
Dimensions: 135 x 24 x 21mm (5.31 x 0.94 x 0.82”)
Probe dimensions: 300 x Φ 1.5mm, 1m cable (11.8 x Φ 0.05, 39.3” cable)
